"Compact structure, high comprehensive precision, good long-term stability, alloy steel and nickel plated surface.
·Electronic platform scales, ingredient scales, packaging scales, garbage classification and recycling cabinets, as well as automation equipment and testing fields Product Usage"
| RATED LOAD | 10/20/30/40/50kg | Output sensitivity | see table±0.2mV/V | ||||
| Lag behind | 0.2%F.S | linear | 0.2%F.S | ||||
| creep | 0.1%F.S(3min) | Repeatability | 0.1%F.S | ||||
| Excitation voltage | 3--10VDO | Zero temperature drift | 0.2%F.S./10℃ | ||||
| Maximum excitation voltage | 15V | Temperature sensitivity drift | 0.2%F.S./10℃ | ||||
| Operating temperature range | (-10~40℃） | Insulation resistance | ≥2000MΩ | ||||
| Overload capacity | 150%F.S. | Output (input) impedance | 1000±10Ω | ||||
| Connection | Red (power+), black (power -), green (signal+), white (signal -) | ||||||
