KD8568-EX AO,Isolated Barrier(2 channels)

KD8568-EX AO,Isolated Barrier(2 channels)

Operation side (HART) isolated barrier,accepts 0/4~20mA signal form safe area to drive valve positioners and other executive mechanisms in hazardous area,also allows bi-directional transmission of HART communication signals.The product needs an independent power supply.Input circuit,output circuit and power supply are each galvanically isolated.

Number of channels: 2inputs/2outputs
Input signal: 0/4~20mA
Output signal: 0/4~20mAOR0/1~5V
Power Supply Mode: 24VDC
Power Connection Mode: Terminal Power SupplyORBus Power Supply
HART: Support
SIL Level: SIL2

Product Name	KD8568-EX Isolated Barrier
Number of channels	2 inputs/2 outputs
Supply voltage(Ue)	20~35V DC
Input signal	0~20mA;4~20mA;HART
Output signal	0~20mA;4~20mA;HART;0~5V;1~5V
Ex-marking	[Ex ia Ga]IIC
Certification	ATEX;IECEx;NEPSI;TUV SIL2
Field apparatus	2-wire valve positioner,electric converter
